Hot-dip aluminized zinc steel sheet is a coated steel sheet made by applying a double-sided hot-dip aluminized zinc alloy coating to cold-rolled steel sheet as the base material. The alloy composition of the coating is 55% Al, 43.5% Zn, and 1.5% Si by mass percentage.
The physical isolation, electrochemical protection, and trivalent aluminum ion doping of the aluminized zinc coating give aluminized zinc steel sheet excellent corrosion resistance.
Under the same conditions, the service life of aluminized zinc steel sheet is 2-6 times that of ordinary galvanized steel sheet.

Cross-sectional Shape
I-beams (I-sections): Their cross-sectional shape resembles a capital "I," with a narrow, high web and relatively wide flanges. The inner surface of the flanges is typically inclined, making the flanges thinner at the ends and thicker at the root.
H-beams: The cross-sectional shape of H-beams is closer to the letter "H." Compared to I-beams, H-beams have wider flanges, and the inner surfaces of the flanges are parallel, meaning the thickness of the flanges is uniform throughout.

Manufacturing Process
I-beams: Typically manufactured through hot rolling or cold bending. Due to their specific cross-sectional shape, the manufacturing process of I-beams is relatively more complex.
H-beams: Can be produced by hot rolling or welding. Modern mass-produced H-beams mostly use hot rolling, which results in more uniform product quality and a higher strength-to-weight ratio.

Mechanical Properties
I-beams: Due to the inclined design of the inner surface of the flanges, the stress distribution of I-beams under lateral forces is less uniform than that of H-beams, and their torsional resistance is relatively weaker.
H-beams possess superior mechanical properties, particularly excelling in bearing vertical loads. Their symmetrical design ensures a more uniform stress distribution under load, while also providing excellent resistance to bending, shearing, and torsion.

H-beams and I-beams are different in shape.

I-beams are mainly divided into ordinary I-beams, lightweight I-beams, and wide-flange I-beams. Based on the flange-to-web height ratio, they are further divided into wide, medium, and narrow wide-flange I-beams. The first two types are produced in sizes 10-60, corresponding to heights of 10-60cm.

H-beams are a widely used profile in modern steel structure construction. The main difference between them and I-beams lies in the flange design—H-beams have no inclination, and the upper and lower surfaces are parallel, providing more uniform cross-sectional properties. Due to their optimized cross-sectional area distribution and strength-to-weight ratio, H-beams have become an economical and efficient profile choice.

I-beams: Due to their relatively high and narrow cross-sectional dimensions, I-beams have a significant difference in moments of inertia about their two principal axes, making them suitable for members subjected to bending within the plane of their web or for forming lattice-type load-bearing members. However, I-beams are not suitable for applications requiring axial compression or bending perpendicular to the web plane.

H-beams: H-beams offer higher load-bearing capacity and better structural stability, making them suitable for high-rise buildings, heavy-duty factories, large bridges, and other projects with high requirements for structural strength and stability. Their optimized cross-sectional design allows for efficient use of steel, increasing load-bearing capacity and facilitating connection with other components using high-strength bolts.

I-beams: Flexible design, easy to cut and weld; resistant to aging, long service life; lightweight, convenient construction, helping to shorten construction time; aesthetically pleasing, meeting general aesthetic standards; possesses good insulation, magnetic permeability, and fire-retardant properties.

H-beams: High structural strength, saving metal materials; diverse design styles, more flexible building layout; lightweight, reducing foundation requirements and lowering costs; good structural stability, particularly suitable for buildings in earthquake-prone areas; increases usable area, improving economic efficiency; easy to process, connect, and install, supporting industrialized manufacturing.
